Description

Camera
Image Sensor:	\|	1/3″ Progressive Scan CMOS
Min. Illumination:	\|	0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR 0.028 Lux @ (F2.0, AGC ON) ,0 Lux with IR
Shutter time:	\|	1/3 s to 1/100,000 s
Lens:	\|	4mm@ F2.0 (2.8mm, 6mm optional), Angle of view: 92.5°(2.8mm), 73.1°(4mm) , 46°(6mm)
Lens Mount:	\|	M12
Adjustment Range:	\|	Pan:0° – 355°, Tilt: 0° – 75°, Rotation: 0-355°
Day& Night:	\|	IR cut filter with auto switch
Wide Dynamic Range:	\|	Digital WDR
Digital noise reduction:	\|	3D DNR
Compression Standard
Video Compression:	\|	H.264/MJPEG
H.264 code profile:	\|	Main Profile
Video bit rate:	\|	32Kbps~12Mbps
Audio Compression:	\|	-S: G.711/G.722.1/G.726/MP2L2
Audio bit rate:	\|	64Kbps(G.711) /16Kbps(G.722.1)/16Kbps(G.726) /32-128Kbps(MP2L2)
Dual Stream:	\|	Yes
Max. Image Resolution:	\|	1280×960
Frame Rate:	\|	50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720) 60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720)
Image Settings:	\|	Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC:	\|	Yes, zone configurable
ROI:	\|	Support
Network
Network Storage:	\|	Built-in Micro SD/SDHC/SDXC slot, up to 64G, NAS(NFS, SMB/CIFS)
Alarm Trigger:	\|	Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols:	\|	TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
Security:	\|	One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering, Anonymous access
System Compatibility:	\|	ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
Wi-Fi Specification (-W)
Wireless Standards:	\|	IEEE802.11b, 802.11g, 802.11n
Frequency Range:	\|	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth:	\|	20/40MHz Support
Modulation Mode:	\|	802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM
Security:	\|	64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Power:	\|	11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm
Receive Sensitivity:	\|	11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical)
Transmission Rate:	\|	11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps
Wireless Range:	\|	50m(depend on environment)
Protocols:	\|	802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM
General
Operating Conditions:	\|	-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply:	\|	12 VDC ± 10%, PoE (802.3af)
Power Consumption:	\|	Max. 5W
Impact Protection:	\|	IK08(-W model)/IK10(non -W model)
Weather Proof:	\|	IP66
IR Range:	\|	Up to 30m
Dimensions:	\|	Φ111 × 82 (4.4” × 3.2”)
Weight:	\|	500g (1.1 lbs)
NOTE：:	\|	“-W” series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support the 802.1X protocol.
