Description
Camera | |
Image Sensor | 1/3″ Progressive Scan CMOS |
Min. Illumination | 0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR 0.028Lux @ (F2.0, AGC ON) ,0 Lux with IR |
Shutter time | 1/3 s to 1/100,000 s |
Lens | 4mm @ F2.0, (2.8mm, 6mm optional) Angle of view: 92.5°(2.8mm), 73.1°(4mm) , 46°(6mm) |
Lens Mount | M12 |
Adjustment Range | Pan:0° – 355°, Tilt: 0° – 75°, Rotation: 0-355° |
Day& Night | IR cut filter with auto switch |
Wide Dynamic Range | Digital WDR |
Digital noise reduction | 3D DNR |
Compression Standard | |
Video Compression | H.264/MJPEG |
H.264 code profile | Baseline Profile / Main Profile |
Video bit rate | 32Kbps~8Mbps |
Dual Stream | Yes |
Image | |
Max. Image Resolution | 1280×960 |
Frame Rate | 50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720) 60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720) |
Image Settings | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
BLC | Yes, zone configurable |
ROI | Support |
Network | |
Network Storage | Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS) |
Alarm Trigger | Tampering alarm, Network disconnect , IP address conflict, Storage exception |
Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
Security | One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering, Anonymous access |
System Compatibility | ONVIF, PSIA, CGI, ISAPI |
Interface | |
Communication Interface | 1 RJ45 10M / 100M Ethernet interface |
On-board storage | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Wi-Fi Specification (-W) | |
Wireless Standards | IEEE802.11b, 802.11g, 802.11n |
Frequency Range | 2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth | 20/40MHz Support |
Modulation Mode | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Transmission Rate | 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
Wireless Range | 50m(depend on environment) |
General | |
Operating Conditions | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
Power Supply | 12 VDC ± 10%, PoE (802.3af) |
Power Consumption | MAX. 5W |
Impact Protection | IK10 |
Weather Proof | IP67 |
IR Range | Up to 30m |
Dimensions | Φ111 × 82 (4.4” × 3.2”) |
Weight | 500g (1.1 lbs) |
NOTE | “-W” series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support the 802.1X protocol. |
