Description

Camera
Image Sensor: | 1/4″ progressive scan CMOS
Signal System: | PAL/NTSC
Min. Illumination: | 0.01Lux @(F1.2,AGC ON) ,0 Lux with IR
0.028Lux @ (F2.0, AGC ON) ,0 Lux with IR
Shutter time: | 1/3 s to 1/100,000 s
Lens: | 4mm@ F2.0, Angle of view: 55
(2.8mm, 6mm optional)
Lens Mount: | M12
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | Digital WDR
Digital noise reduction: | 3D DNR
Compression Standard
Video Compression: | H.264/MJPEG
H.264 code profile: | Main Profile
Video bit rate: | 32Kbps~8Mbps
Audio Compression: | -S: G.711/G.722.1/G.726/MP2L2
Audio bit rate: | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2)
Max. Image Resolution: | 1280 720
Frame Rate: | 50 Hz: 25 fps (1280 x 720), 25 fps (704 x 576), 25 fps (640 x 480)
60 Hz: 30 fps (1280 x 720), 30 fps (704 x 576), 30 fps (640 x 480)
Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
BLC: | Yes, zone configurable
ROI: | support
3D DNR: | support
Network
Network Storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS)
Alarm Trigger: | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols: | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
General Function: | One-key recovery, flash-prevention, three streams, heartbeat, mirror, password protection, video
mask, Watermark, IP address filtering, Anonymous access
System Compatibility: | ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface: | 1 RJ45 10M / 100M Ethernet interface
