Description
| Camera | ||
|---|---|---|
| Image Sensor: | 1/4″ progressive scan CMOS | |
| Min. Illumination: | 0.02Lux @ (F1.2, AGC ON), 0 Lux with IR | |
| Shutter time: | 1/3 s to 1/100,000 s | |
| Slow shutter: | Support | |
| Lens: | 2.8mm, horizontal field of view 92° | |
| Lens Mount: | M12 | |
| Day& Night: | IR cut filter with auto switch | |
| Wide Dynamic Range: | Digital WDR | |
| Digital noise reduction: | 3D DNR | |
| Compression Standard | ||
|---|---|---|
| Video Compression: | H.264 | |
| H.264 code profile: | Baseline Profile/Main Profile | |
| Video bit rate: | 32Kbps~8Mbps | |
| Audio Compression: | G.711/G.722.1/G.726/MP2L2 | |
| Audio bit rate: | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2) | |
| Image | ||
|---|---|---|
| Max. Image Resolution: | 1280 × 720 | |
| Sub Stream: | 50Hz: 25fps (1280 × 720) 60Hz: 30fps (1280 × 720) |
|
| Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser | |
| BLC: | Yes, zone configurable | |
| ROI: | Support 1 fixed region for each stream | |
| Day/Night Switch: | Support auto/scheduled | |
| Network | ||
|---|---|---|
| Alarm Trigger: | Video tampering, alarm input, alarm output, network disconnected, IP address conflict, illegal login, HDD full, HDD error | |
| Protocols: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv6, Bonjour, SMTP, 802.1x | |
| Interface | ||
|---|---|---|
| Audio: | Internal Microphone and Speaker | |
| On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB | |
| Reset Button: | Yes | |
| Wi-Fi Specification (-W) | ||
|---|---|---|
| Wireless Standards: | IEEE802.11b, 802.11g, 802.11n | |
| Frequency Range: | 2.4 GHz ~ 2.4835 GHz | |
| Channel Bandwidth: | 20/40MHz Support | |
| Security: | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS | |
| Transmission Rate: | 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
|
| Wireless Range: | 50m(depend on environment) | |
| Protocols: | 802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM | |
| General | ||
|---|---|---|
| Memory Card: | DS-2CV2Q01FD-IW: no memory card included DS-2CV2Q01FD-IW/16G-T: includes a 16 GB memory card DS-2CV2Q01FD-IW/32G-T: includes a 32 GB memory card DS-2CV2Q01FD-IW/64G-T: includes a 64 GB memory card |
|
| Operating Conditions: | -10°C ~ 40°C (14°F ~ 104°F), Humidity 95% or less (non-condensing) | |
| Power Supply: | DC 5V ± 10 %, micro USB interface | |
| Power Consumption: | Max. 7W | |
| IR Range: | Up to 5 meters | |
| Dimensions: | Φ 82.4 × 113.6 mm (Φ 3.25′ × 4.47′) | |
| Weight: | Approx. 510g (1.12 lb) | |
