Description

Camera
Image Sensor:		1/2.8″ Progressive Scan CMOS
Min. Illumination:		0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR 0.028 Lux @ (F2.0, AGC ON) ,0 Lux with IR
Shutter time:		1/3 s to 1/100,000 s
Lens:		4mm @ F2.0, (2.8mm, 6mm optional) Angle of view: 106°(2.8mm), 85°(4mm) , 52°(6mm)
Lens Mount:		M12
Adjustment Range:		Pan:0° – 355°, Tilt: 0° – 75°, Rotation: 0-355°
Day& Night:		IR cut filter with auto switch
Wide Dynamic Range:		Digital WDR
Digital noise reduction:		3D DNR

Max. Image Resolution:		1920 x 1080
Frame Rate:		50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720) 60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720)
Image Settings:		Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC:		Yes, zone configurable
ROI:		Support

Network
Network Storage:		Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS)
Protocols:		TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
System Compatibility:		ONVIF, PSIA, CGI, ISAPI

Interface
Communication Interface:		1 RJ45 10M / 100M Ethernet interface
On-board storage:		Built-in Micro SD/SDHC/SDXC slot, up to 128 GB

General
Operating Conditions:		-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply:		12 VDC ± 10%, PoE (802.3af)
Power Consumption:		Max. 5 W
Impact Protection:		IK10
IR Range:		Up to 30m
Dimensions:		Φ111 × 82 (4.4” × 3.2”)
Weight:		500g (1.1 lbs)
