Description

SPECIFICATIONS
Brand	Hikvision
Model	Hikvision – DS-2CD2420F-I
Type	2MP IR Cube Camera
CAMERA
Image Sensor	1/2.8″ Progressive Scan CMOS
Min. Illumination	0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR 0.028 Lux @ (F2.0, AGC ON) ,0 Lux with IR
Shutter Time	1/3 s to 1/100,000 s
Lens	4mm@ F2.0, Angle of view: 85° (2.8mm, 6mm optional)
Lens Mount	M12
Day& Night	IR cut filter with auto switch
Wide Dynamic Range	Digital WDR
Digital noise reduction	3D DNR
COMPRESSION STANDARD
Video Compression	H.264/MJPEG
H.264 code profile	Main Profile
Video bit rate	32Kbps~8Mbps
Audio Compression	G.711/G.722.1/G.726/MP2L2
Audio bit rate	64Kbps(G.711) /16Kbps(G.722.1)/16Kbps(G.726) /32-128Kbps(MP2L2)
Max. Image Resolution	1920 x 1080
Frame Rate	50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720), 60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720)
BLC	Yes, zone configurable
ROI	support
NETWORK
Network Storage	Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS)
Protocols	TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, NTP,UPnP,SMTP,IGMP,802.1X,QoS,IPv6,Bonjour
System Compatibility	ONVIF (Profile S, Profile G),ISAPI
INTERFACE
Communication Interface	1 RJ45 10M / 100M Ethernet interface
Alarm Input	1
Alarm Ouput	1
GENERAL
Operating Conditions:	-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)
Power Supply:	12 VDC ± 10%, PoE (802.3af)
Power Consumption:	5.5W MAX
IR Range:	10 meters
PIR:	Angle: 80° Range: 10m
Dimensions	72.3×89.9×131.3
Weight	400g(0.88lbs)
