Description
Specifications
| Name | HIKVISION DS-2CD2420F-IW |
| Video system | IP |
| Housing type | Compact (cube) |
| Compression | H.264/MJPEG |
| Resolution | 1920×1080 |
| Dual-stream | Yes |
| Frame rate | 25 fps at 1920×1080 and lower resolutions |
| Image sensor | 1/2.8″ Progressive Scan CMOS |
| Sensitivity | 0.28 lx @F2.0 with AGC 0 lx in IR mode |
| Lens | 2.8 mm / 98.5° |
| Mechanically switching IR filter | Yes |
| IR range | up to 10 m |
| Brightness control | Yes |
| Sharpness control | Yes |
| ROI | Yes |
| Video processing | 3D-DNR, D-WDR, BLC |
| Gain | Automatic/Preset |
| Alarm events | Motion detection, dynamic analysis, tampering |
| Intelligent image analysis | Yes |
| Line crossing | 1 line |
| Intruder detection | 1 region |
| ROI | 1 region |
| Recording | NVR, memory card, FTP/NAS server |
| Network interface | RJ-45 10/100Base-T |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| ONVIF | Yes |
| Wi-Fi (2.4 GHz) | IEEE802.11b, 802.11g, 802.11n |
| PIR sensor (angle / range) | 80°/ 10 m |
| Power | 12 VDC ± 10% PoE IEEE 802.3af |
| Power consumption | 5 W (max 7 W with IR) |
| Operating temperature range | -30°C … 60°C |
| Dimensions | 72.3 x 89.9 x 131.3 mm |
| Weight | 0.4 kg |
