Description
Camera
Image Sensor: | 1/2.7 Progressive Scan CMOS
Min. Illumination: | 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter time: | 1/3 s to 1/100,000 s
Lens: | 2.7-12mm @ F1.4, horizontal field of view: 113 to 33.8
Lens Mount: | 14
Adjustment Range: | Pan:0 – 355, Tilt: 0 – 75, Rotation: 0 – 355
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | Digital WDR
Digital noise reduction: | 3D DNR
Compression Standard
Video Compression: | H.264/MJPEG
H.264 code profile: | BaseLine Profile/Main Profile
Video bit rate: | 32Kbps~8Mbps
Audio Compression: | G.711/G.722.1/G.726/MP2L2
Audio bit rate: | 64Kbps(G.711)/ 16Kbps(G.722.1)/ 16Kbps(G.726)/ 32-128Kbps(MP2L2)
Dual Stream: | Yes
Max. Image Resolution: | 1920 x 1080
Frame Rate: | 50Hz: 25fps (1920 1080,1280 960,1280 720)
60Hz: 30fps (1920 1080,1280 960,1280 720)
Image Settings: | Saturation, brightness, contrast adjustable through client software or web browser
BLC: | Yes, zone configurable
ROI: | Support
Network
Network Storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS)
Alarm Trigger: | Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols: | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
Security: | Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access
System Compatibility: | ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface: | 1 RJ45 10M / 100M Ethernet interface
On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
General
Operating Conditions: | -30 C ~ 60 C (-22 F ~ 140 F)
Humidity 95% or less (non-condensing)
Power Supply: | 12 VDC 10%, PoE (802.3af)
