Description
Camera | ||
---|---|---|
Image Sensor: | 1/2.8″ Progressive Scan CMOS | |
Min. Illumination: | 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR | |
Shutter time: | 1/3 s to 1/100,000 s | |
Slow shutter: | Support | |
Lens: | 2.8 mm, horizontal field of view 105.8° | |
Lens Mount: | M12 | |
Day& Night: | IR cut filter with auto switch | |
Wide Dynamic Range: | Digital WDR | |
Digital noise reduction: | 3D DNR |
Compression Standard | ||
---|---|---|
Video Compression: | H.264 | |
H.264 code profile: | Baseline Profile/Main Profile | |
Video bit rate: | 32Kbps~8Mbps | |
Audio Compression: | G.711/G.722.1/G.726/MP2L2 | |
Audio bit rate: | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2) |
Image | ||
---|---|---|
Max. Image Resolution: | 1920 x 1080 | |
Sub Stream: | 50Hz: 25fps (1920 × 1080, 1280 ×720) 60Hz: 30fps (1920 × 1080, 1280 ×720) |
|
Image Settings: | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser | |
BLC: | Yes, zone configurable | |
ROI: | Support 1 fixed region for each stream | |
Day/Night Switch: | Support auto/scheduled |
Network | ||
---|---|---|
Alarm Trigger: | Video tampering, alarm input, alarm output, network disconnected, IP address conflict, illegal login, HDD full, HDD error | |
Protocols: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv6, Bonjour, SMTP, 802.1x |
Interface | ||
---|---|---|
Audio: | Internal Microphone and Speaker | |
On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB | |
Reset Button: | Yes |
Wi-Fi Specification (-W) | ||
---|---|---|
Wireless Standards: | IEEE802.11b, 802.11g, 802.11n | |
Frequency Range: | 2.4 GHz ~ 2.4835 GHz | |
Channel Bandwidth: | 20/40MHz Support | |
Transmission Rate: | 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
|
Wireless Range: | 50m(depend on environment) | |
Protocols: | 802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
General | ||
---|---|---|
Memory Card: | DS-2CV2Q21FD-IW: no memory card included DS-2CV2Q21FD-IW/16G-T: includes a 16 GB memory card DS-2CV2Q21FD-IW/32G-T: includes a 32 GB memory card DS-2CV2Q21FD-IW/64G-T: includes a 64 GB memory card |
|
Operating Conditions: | -10°C ~ 40°C (14°F ~ 104°F), Humidity 95% or less (non-condensing) | |
Power Supply: | DC 5V ± 10 %, micro USB interface | |
Power Consumption: | Max. 7W | |
IR Range: | Up to 5 meters | |
Dimensions: | Φ 82.4 × 113.6 mm (Φ 3.25′ × 4.47′) | |
Weight: | Approx. 510g (1.12 lb) |
