Description
| Camera | ||
|---|---|---|
| Image Sensor: | | | 2MP CMOS Image Sensor |
| Signal System: | | | PAL/NTSC |
| Effective Pixels: | | | 1930(H) × 1088(V) |
| Min. Illumination: | | | 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR |
| Shutter Time: | | | 1/25(1/30) s to 1/50,000 s |
| Lens: | | | Motorized VF lens; 2.8 – 12 mm @ F1.4, Angle of view: 35.1°- 114.5° |
| Lens Mount: | | | φ14 |
| Adjustment Range: | | | Pan: 0 – 340°, Tilt: 0 – 75°, Rotation: 0 – 355° |
| Day& Night: | | | IR cut filter with auto switch |
| Video Frame Rate: | | | 1080p@25fps/1080p@30fps |
| HD Video Output: | | | 1 Analog HD output |
| Synchronization: | | | Internal Synchronization |
| S/N Ratio: | | | More than 62 dB |
| Menu | ||
| Camera ID: | | | On/Off (0-255) |
| D/N Mode: | | | Color/ BW/ Auto/ EXT |
| Auto White Balance: | | | Auto/User/Push/8000K/6000K/4200K/3000K |
| Private Mask: | | | On/Off, maximum 8 zones |
| Motion Detection: | | | On/Off, maximum 4 zones |
| BLC: | | | On/Off |
| AGC: | | | Support |
| Anti-flicker: | | | On/ Off |
| Language: | | | English/Chinese |
| Function: | | | Digital noise reduction, Mirror |
| General | ||
| Operating Conditions: | | | -20 °C – 45 °C (-4 °F – 113 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | | | 12 VDC±15% -A: 12 VDC±15%, 24 VAC±15% |
| Power Consumption: | | | Max. 4W -A: Max. 5W |
| IR Range: | | | Up to 30m |
| Communication : | | | Up the coax |
| Dimension: | | | Φ 136 × 101.94 mm (Φ 5.35” × 4.01”) |
| Weight: | | | 560 g |
