Description
| Camera | ||
|---|---|---|
| Image Sensor: | 2MP CMOS Image Sensor | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1944(H)×1092(V) | |
| Min. Illumination: | 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR 0.014 Lux @ (F1.4,AGC ON),0 Lux with IR |
|
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens: | Motorized VF lens; 2.8 – 12 mm @ F1.4, Angle of view: 103° – 32.1° | |
| Lens Mount: | φ14 | |
| Adjustment Range: | Pan: 0 – 340°, Tilt: 0 – 75°, Rotation: 0 – 355° | |
| Day& Night: | IR cut filter with auto switch | |
| Video Frame Rate: | 1080p@25fps/1080p@30fps | |
| HD Video Output: | 1 Analog HD output | |
| Synchronization: | Internal Synchronization | |
| CVBS Output: | 1Vp-p Composite Output(75Ω/BNC) | |
| S/N Ratio: | More than 62 dB | |
| Up the Coax: | Support | |
| Menu | ||
|---|---|---|
| Camera ID: | On/off (15 characters, position programmable) | |
| D/N Mode: | Color/ BW/ EXT | |
| Auto White Balance: | ATW/ AWC-SET/ Indoor/ Outdoor/ Manual | |
| Private Mask: | On/Off, maximum 8 zones | |
| Motion Detection: | On/Off, maximum 4 zones | |
| BLC: | On/Off | |
| AGC: | Support | |
| Anti-flicker: | On/ Off | |
| Language: | English/ Japanese/ CHN1/ CHN2/ Korean/ German/ French/ Italian/ Spanish/ Polish/ Russian/ Portuguese/ Dutch/ Turkish/ Hebrew/ Arabic | |
| Function: | Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM |
|
| Scene: | Indoor, Outdoor, Indoor1, LOW-LIGHT | |
| General | ||
|---|---|---|
| Operating Conditions: | -20 °C – 45 °C (-4 °F – 113 °F) Humidity 90% or less (non-condensing) |
|
| Power Supply: | 12 VDC±15%, 24 VAC±15% | |
| Power Consumption: | Max. 6W | |
| IR Range: | Up to 30m | |
| Communication : | Up the coax Protocol: Pelco-C(CVBS output), HIKVISION-C(TVI output) |
|
| Dimension: | Φ 136 × 101 mm (Φ 5.35” × 3. 98”) | |
| Weight: | 560 g | |
