Description
Camera
Image Sensor
- 1.27MP CMOS Image Sensor
Signal System
- PAL/NTSC
Effective Pixels
- 1305(H)*977(V)
Min. illumination
- 0.001 Lux @(F1.2,AGC ON), 0 Lux with IR
Shutter Time
- 1/25(1/30)s to 1/50,000s
Lens
- 2.8 – 12 mm @ F1.4
- Angle of view: 92° – 29.3°
Lens Mount
- f14
Day and Night
- ICR
Angle Adjustment
- Pan: 0 – 340°, Tilt: 0 – 75°, Rotation: 0 – 355°
Synchronisation
- Internal synchronisation
Video Frame Rate
- 720p@25fps/720p@30fps
HD Video Output
- 1 Analogue HD output
CVBS Output
- 1Vp-p Composite Output(75O/BNC)
S/N Ratio
- >62dB
Menu
Automatic Exposure
- Globe AE/DWDR
AGC
- Low/Middle/High/Off
Slow Shutter
- Support
White Balance
- Auto/Manual
D/N Mode
- Color/BW/SMART IR
3D DNR
- Low/Middle/High/Off
Motion Detection
- Support, maximum 4 zones
Privacy Mask
- On/Off, maximum 8 zones
Language
- English/Chinese
Function
- Digital Wide Dynamic Range, 3D Digital Noise Reduction, Sharpness, Brightness, Digital Zoom, Mirror,Reset
General
Operating Conditions
- -20 C – 45 C (-4 F – 113 F), Humidity 90% or less (non-condensing)
Power Supply
- 12 VDC±15%; -A: 12 VDC±15% 24 VAC±15%,
Power Consumption
- Max. 4W; -A: Max. 5W
IR Range
- Up to 30m
Communication
- Up the coax, Protocol: Pelco-C(CVBS output), HIKVISION-C(TVI output)
Dimensions
- F136 × 101 mm (F 5.35” × 3. 98”)
Weight
- 600 g
