Description
| Camera | ||
|---|---|---|
| Image Sensor: | 2MP CMOS Image Sensor | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1920(H)*1080(V) | |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens Mount: | φ14 | |
| Auto Iris: | Support | |
| Adjustment Range: | Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° | |
| Day& Night: | IR cut filter with auto switch | |
| Wide Dynamic Range: | 120dB | |
| Video Frame Rate: | PAL: 1080p@25fps NTSC: 1080p@30fps |
|
| HD Video Output: | 1 Analog HD output | |
| Synchronization: | Internal Synchronization | |
| CVBS Output: | 1Vp-p Composite Output(75Ω/BNC) | |
| Menu | ||
|---|---|---|
| Voltage Detection: | Support | |
| D/N Mode: | Auto / Color / B/W | |
| AGC: | Support | |
| Scene: | Indoor/outdoor/indoor1/low light | |
| General | ||
|---|---|---|
| Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
|
| Weather Proof: | IP67 | |
| IR Range: | Up to 40m | |
| Communication : | Up the coax Protocol: HIKVISION-C(Coaxitron) |
|
| Dimension: | 92 mm × 85.3 mm ×269.6 mm (3.62″ × 3.36″ × 10.61″) | |
| Weight: | Approx. 700 g (1.54 lb.) | |
