Description

Camera
Image Sensor:		2MP CMOS Image Sensor
Signal System:		PAL/NTSC
Effective Pixels:		1920(H)*1080(V)
Min. Illumination:		0.003 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time:		1/25(1/30) s to 1/50,000 s
Lens:		M 12
Lens Mount:		M12
Adjustment Range:		Pan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360°
Day& Night:		IR cut filter with auto switch
Wide Dynamic Range:		120dB
Video Frame Rate:		PAL: 1080p@25fps NTSC: 1080p@30fps
HD Video Output:		1 Analog HD output
Synchronization:		Internal Synchronization
CVBS Output:		1Vp-p Composite Output(75Ω/BNC)

Menu
Voltage Detection:		Support
D/N Mode:		Auto / Color / B/W
Auto White Balance:		ATW/AWC-SET/MANUAL
Private Mask:		ON/OFF, 8 programmable privacy masks
Motion Detection:		4 programmable motion areas
Function:		Defog, Mirror, Defective Pixel Correction, Sharpness, Camera Title
Scene:		Indoor/outdoor/indoor1/low light

General
Operating Conditions:		-40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing)
Power Supply:		12 V DC ±30%/PoC.af
Power Consumption:		Max.: 5.5 W
Weather Proof:		IP67
IR Range:		Up to 80m
Communication :		Up the coax Protocol: HIKVISION-C(Coaxitron)
Dimension:		86.7 mm × 81.6 mm × 226 mm (3.4″ × 3.2″ ×8.9″)
Weight:		Approx. 800 g (1.76 lb.)
