Description

Camera
Image Sensor:		2.0 megapixel progressive scan CMOS
Signal System:		PAL/NTSC
Effective Pixels:		1920(H)*1080(V)
Shutter Time:		1/25(1/30) s to 1/50,000 s
Lens Mount:		M12
Adjustment Range:		Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
Day& Night:		IR cut filter
Video Frame Rate:		PAL: 1080p@25fps NTSC: 1080p@30fps
HD Video Output:		1 Analog HD output
Synchronization:		Internal Synchronization
Up the Coax:		Support

Menu
Backlight Compensation:		Yes
D/N Mode:		Color/BW/SMART
AGC:		Low/middle/high
Digital WDR:		Yes
Language:		English/Chinese
Function:		Brightness, Sharpness, DNR, Mirror

Interface
Video Out:		1 HD analog output

General
Material:		Metal
Operating Conditions:		-40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing)
Power Supply:		12 VDC±15%
Power Consumption:		Max. 7 W
Weather Proof:		IP66
IR Range:		Up to 30m
Dimension:		Ø 70 mm × 154.5 mm (Ø 2.76″ × 6.08″)
Weight:		Approx. 310 g (0.68 lb.)
