Description

Camera
Image Sensor	2MP CMOS Image Sensor
Signal System	PAL/NTSC
Effective Pixels	1930(H) × 1088(V)
Min. Illumination	0.01 Lux @ (F1.2,AGC ON),0 Lux with IR 0.014 Lux @ (F1.4,AGC ON),0 Lux with IR
Shutter Time	1/25(1/30) s to 1/50,000 s
Lens	Motorized VF lens; 2.8 – 12 mm @ F1.4 , Angle of view: 114.5° – 35.1°
Lens Mount	φ14
Adjustment Range	Pan: 0 – 360°, Tilt: 0 – 90°, Rotation: 0 – 360°
Day& Night	IR cut filter with auto switch
Video Frame Rate	1080p@25fps/1080p@30fps
HD Video Output	1 Analog HD output
Synchronization	Internal Synchronization
S/N Ratio	More than 62 dB
Up the Coax	Support
Menu
Camera ID	On/Off (0-255)
D/N Mode	Color/ BW/ Auto/ EXT
Auto White Balance	Auto/User/Push/8000K/6000K/4200K/3000K
Private Mask	On/Off, maximum 8 zones
Motion Detection	On/Off, maximum 4 zones
BLC	On/Off
AGC	Support
Anti-flicker	On/ Off
Language	English/Chinese
Function	Digital noise reduction, Mirror
General
Operating Conditions	-40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing)
Power Supply	12 VDC±15%
Power Consumption	Max. 5W
Weather Proof	IP66
IR Range	Up to 40m
Communication	Up the coax Protocol: HIKVISION-C(Coaxitron)
Dimension	92 × 84.8 × 269.6mm(3.62” × 3.34” × 10.6”)
Weight	720g (1.59 lb)
