Description
Camera | ||
---|---|---|
Image Sensor: | 2MP CMOS Image Sensor | |
Signal System: | PAL/NTSC | |
Effective Pixels: | 1930(H) × 1088(V) | |
Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
Lens Mount: | M12 | |
Adjustment Range: | Pan: 0 – 360°, Tilt: 0 – 180°, Rotation: 0 – 360° | |
Day& Night: | IR cut filter with auto switch | |
Video Frame Rate: | 1080p@25fps/1080p@30fps | |
HD Video Output: | 1 Analog HD output | |
Synchronization: | Internal Synchronization | |
S/N Ratio: | More than 62 dB |
Menu | ||
---|---|---|
Camera ID: | On/Off (0-255) | |
D/N Mode: | Color/ BW/ Auto/ EXT | |
Auto White Balance: | Auto/User/Push/8000K/6000K/4200K/3000K | |
Private Mask: | On/Off, maximum 8 zones | |
Motion Detection: | On/Off, maximum 4 zones | |
AGC: | Support | |
Language: | English/Chinese |
General | ||
---|---|---|
Operating Conditions: | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
|
Power Supply: | 12 VDC±15% | |
Weather Proof: | IP66 | |
IR Range: | Up to 80m | |
Communication : | Up the coax Protocol: HIKVISION-C(Coaxitron) |
|
Dimension: | 86.22×82.05×220.13mm(3.39”×3.23”×8.67”) | |
Weight: | 430 g (0.95 lbs) |
