Description

Camera
Image Sensor:		2MP CMOS Image Sensor
Signal System:		PAL/NTSC
Effective Pixels:		1944(H)×1092(V)
Min. Illumination:		0.01 Lux @(F1.2,AGC ON), 0 Lux with IR
Shutter Time:		1/25(1/30) s to 1/50,000 s
Lens:		3.6mm (2.8mm, 6mm, 8mm optional) Angle of View: 82.6°(3.6mm), 103.5°(2.8mm), 54.4°(6mm), 38°(8mm)
Lens Mount:		M12
Adjustment Range:		Pan: 0 – 360°, Tilt: 0 – 180°, Rotation: 0 – 360°
Day& Night:		IR cut filter with auto switch
Wide Dynamic Range:		120dB
Video Frame Rate:		1080p@25fps/1080p@30fps
HD Video Output:		1 Analog HD output
Synchronization:		Internal Synchronization
CVBS Output:		1Vp-p Composite Output(75Ω/BNC)
S/N Ratio:		More than 62 dB
Up the Coax:		Support

Menu
Camera ID:		On/off (15 characters, position programmable)
D/N Mode:		Color/ BW/ EXT
Auto White Balance:		ATW/ AWC-SET/ Indoor/ Outdoor/ Manual
Private Mask:		On/Off, maximum 8 zones
Motion Detection:		On/Off, maximum 4 zones
BLC:		On/Off
AGC:		Support
Anti-flicker:		On/ Off
Language:		English/ Japanese/ CHN1/ CHN2/ Korean/ German/ French/ Italian/ Spanish/ Polish/ Russian/ Portuguese/ Dutch/ Turkish/ Hebrew/ Arabic
Function:		Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM
Scene:		Indoor, Outdoor, Indoor1, LOW-LIGHT

General
Operating Conditions:		-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 90% or less (non-condensing)
Power Supply:		12 VDC±15%
Power Consumption:		Max. 4W
Weather Proof:		IP66
IR Range:		Up to 20m
Dimension:		94.6×83×210.8mm(3.72”×3.27”×8.30”)
Weight:		700 g (1.54 lbs)
