Description
| Camera | ||
|---|---|---|
| Image Sensor: | 1.27MP CMOS Image Sensor | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1305(H)x977(V) | |
| Min. Illumination: | 0.001 Lux @(F1.2,AGC ON), 0 Lux with IR | |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens: | 2.8-12mm @ F1.4 Angle of view: 92° – 29.3° |
|
| Lens Mount: | φ14 | |
| Adjustment Range: | Pan: 0 – 360°, Tilt: 0 – 75°, Rotation: 0 – 360° | |
| Day& Night: | IR cut filter with auto switch | |
| Video Frame Rate: | 720p@25fps/720p@30fps | |
| HD Video Output: | 1 Analog HD output | |
| Synchronization: | Internal Synchronization | |
| CVBS Output: | 1Vp-p Composite Output(75Ω/BNC) | |
| S/N Ratio: | More than 62 dB | |
| Up the Coax: | Support | |
| Menu | ||
|---|---|---|
| Automatic Exposure: | Globe AE/DWDR | |
| Auto Gain: | Low/Middle/High/Off | |
| D/N Mode: | Color/ BW/ EXT | |
| Auto White Balance: | Auto / Manual | |
| Private Mask: | On/Off, maximum 8 zones | |
| Motion Detection: | On/Off, maximum 4 zones | |
| Language: | English/Chinese | |
| Function: | Digital Wide Dynamic Range, 3D Digital Noise Reduction, Sharpness, Brightness, Digital Zoom, Mirror | |
| General | ||
|---|---|---|
| Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 90% or less (non-condensing) |
|
| Power Supply: | 12 VDC±15% | |
| Power Consumption: | Max. 6.5W | |
| Weather Proof: | IP66 | |
| IR Range: | Up to 50m | |
| Communication : | Up the coax Protocol: Pelco-C(CVBS output), HIKVISION-C(TVI output) |
|
| Dimension: | φ130.54 × 93.24 mm (φ5.14” × 3. 67”) | |
| Weight: | 670 g | |
