Description

Video/Audio Input
Audio Input:	\|	8-ch
Video Compression:	\|	H.265+/H.265/H.264+/H.264
Analog and HD-TVI video input:	\|	8-ch,BNC interface (1.0Vp-p, 75 Ω)connection
Supported camera types:	\|	Support HDTVI input: 5MP,4MP,3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz, Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz Support CVI input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz Support CVBS input
Video Input Interface:	\|	BNC (1.0 Vp-p, 75Ω)
Audio Compression:	\|	G.711u
Audio Input Interface:	\|	4-ch, RCA (2.0 Vp-p, 1 KΩ)
Two-way Audio:	\|	1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input)
Video/Audio Output
CVBS Output:	\|	1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704×576,NTSC:704×480
HDMI/VGA Output:	\|	VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Recording resolution:	\|	5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame Rate:	\|	Main stream: 5 MP@12fps/4 MP@15fps/3 MP@18fps 1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) Sub-stream: WD1/4CIF/CIF@25fps (P)/30fps (N)
Video Bit Rate:	\|	32 Kbps-10 Mbps
Stream Type:	\|	Video/Video&Audio
Two-way Audio:	\|	1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Audio Output:	\|	1-ch RCA(Linear, 1kΩ)
Audio Bit Rate:	\|	64kbps
Dual Stream:	\|	Support
Playback Resolution:	\|	5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF
Synchronous Playback:	\|	8-ch
Network management
Remote connections:	\|	128
Network protocols:	\|	TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,ONVIF
Hard Disk Driver
Interface Type:	\|	1 SATA Interface
Capacity:	\|	Up to 8 TB capacity for each disk
External Interface
Network Interface:	\|	1; 10M / 100M / 1000M self-adaptive Ethernet interface
USB Interface:	\|	1 USB 2.0 Interface & 1 USB 3.0 Interface
Serial Interface:	\|	1; standard RS-485 serial interface, half-duplex
Alarm Input:	\|	8-ch
Alarm Output:	\|	4-ch
General
Power Supply:	\|	12 VDC
Consumption:	\|	≤ 20W(without hard disks)
Working Temperature:	\|	-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working Humidity:	\|	10% to 90%
Dimensions:	\|	315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)
Weight:	\|	≤ 2 kg (4.4 lb)
