Description
Camera | |
Image Sensor | 1/3’’ Progressive Scan CMOS |
Min. Illumination | 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter time | 1/3s ~ 1/100,000s |
Lens | 2.8 – 12 mm @ F1.4,Angle of view: 98°-30.2° |
Lens Mount | φ14 |
Adjustment Range | Pan: 0° to 360°, Tilt: 0° to 100°, Rotation: 0° to 360° |
Day& Night | IR cut filter with auto switch |
Wide Dynamic Range | Digital WDR |
Digital noise reduction | 3D DNR |
Compression Standard | |
Video Compression | H.264/MJPEG |
H.264 code profile | BaseLine Profile/Main Profile |
Video bit rate | 32Kbps~8Mbps |
Audio Compression | G.711/G.722.1/G.726/MP2L2 |
Audio bit rate | 64Kbps(G.711)/ 16Kbps(G.722.1) / 16Kbps(G.726) /32-128Kbps(MP2L2) |
Dual Stream | Yes |
Image | |
Max. Image Resolution | 1280×960 |
Frame Rate | 50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720), 25 fps (704 x 576), 25 fps (640 x 480) 60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720), 30 fps (704 x 576), 30 fps (640 x 480) |
Image Settings | Saturation, brightness, contrast adjustable through client software or web browser |
BLC | Yes, zone configurable |
ROI | Support |
Network | |
Network Storage | NAS (Support NFS,SMB/CIFS) |
Alarm Trigger | Intrusion detection, Defocus detection, Motion detection, Face detection, Dynamic analysis, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
Protocols | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
Security | Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
System Compatibility | ONVIF, PSIA, CGI, ISAPI |
Interface | |
Communication Interface | 1 RJ45 10M / 100M Ethernet interface |
Video Output | 1Vp-p Composite Output (75 Ω, BNC) |
On-board storage | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
General | |
Operating Conditions | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
Power Supply | 12 VDC ± 10%, PoE (802.3af) |
Power Consumption | Max. 6.8 W |
Weather Proof | IP67 |
IR Range | Approx 20 to 30 meters(65.6-98.4ft) |
Dimensions | 95×105×258.6 mm (3.74” × 4.13” × 10.18”) |
Weight | 1200g |
