Description

Spesifikasi Lengkap Kamera Indoor Hikvision 2MP DS-2CE76D0T-EXIPF

Model	Hikvision DS-2CE76D0T-EXIPF (2.8mm)
Camera
Image Sensor	2 MP CMOS
Max. Resolution	1920 (H) × 1080 (V)
Min. Illumination	0.005 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time	PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s
Day &Night	IR cut filter
Signal System	PAL/NTSC
Angle Adjustment	Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
Lens
Lens	2.8 mm, 3.6 mm, 6 mm
FOV	2.8 mm, horizontal FOV: 106.4°, vertical FOV: 57.9°, diagonal FOV: 124.6° 3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7° 6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8
Lens Mount	M12
Image Enhancement	BLC
Image Parameters Switch	STD/HIGH-SAT
Image Enhancement	BLC, HLC
Image Setting	Brightness, Sharpness, DNR, Mirror, Smart IR
Frame Rate	TVI: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC
White Balance	ATW/MANUAL
Wide Dynamic Range (WDR)	≥ 120 dB
AGC	Support
Day/Night Mode	Auto/Color/BW (Black and White)
Interface
Video Output	Switchable TVI/AHD/CVI/CVBS
General
Meterial	Plastic
Dimensions	89.47 mm × 68.2 mm (3.52″ × 2.68″) Approx. 240 g (0.53 lb.)
Operating Condition	-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Power Supply	12 VDC ±25%,*You are recommended to use one power adapter to supply the power for one camera.
Power Consumption And Current	Max. 2.2 W
Communication	HIKVISION-C
Language	English
IR Range	Up to 20 m
Approval
Protection	IP67
