Description
| Camera | ||
|---|---|---|
| Image Sensor: | 2MP CMOS Image Sensor | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1930(H) × 1088(V) | |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens Mount: | φ14 | |
| Adjustment Range: | Pan: 0 – 340°, Tilt: 0 – 75°, Rotation: 0 – 355° | |
| Day& Night: | IR cut filter with auto switch | |
| Video Frame Rate: | 1080p@25fps/1080p@30fps | |
| HD Video Output: | 1 Analog HD output | |
| Synchronization: | Internal Synchronization | |
| S/N Ratio: | More than 62 dB | |
| Menu | ||
|---|---|---|
| Camera ID: | On/Off (0-255) | |
| D/N Mode: | Color/ BW/ Auto/ EXT | |
| Auto White Balance: | Auto/User/Push/8000K/6000K/4200K/3000K | |
| Private Mask: | On/Off, maximum 8 zones | |
| Motion Detection: | On/Off, maximum 4 zones | |
| BLC: | On/Off | |
| AGC: | Support | |
| Language: | English/Chinese | |
| General | ||
|---|---|---|
| Operating Conditions: | -20 °C – 45 °C (-4 °F – 113 °F) Humidity 90% or less (non-condensing) |
|
| Power Supply: | 12 VDC±15% -A: 12 VDC±15%, 24 VAC±15% |
|
| IR Range: | Up to 30m | |
| Communication : | Up the coax Protocol: HIKVISION-C(Coaxitron) |
|
| Dimension: | Φ 136 × 101.94 mm (Φ 5.35” × 4.01”) | |
| Weight: | 600 g | |
