Description

Camera
Image Sensor	2MP CMOS Image Sensor
Signal System	PAL/NTSC
Effective Pixels	1928(H)*1088(V)
Min. Illumination	0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter Time	1/25(1/30) s to 1/50,000 s
Lens	Motorized VF lens; 2.8 – 12 mm Angel of view: 35.1°-114.5°
Lens Mount	φ14
Adjustment Range	Pan: 0 – 360°, Tilt: 0 – 75°, Rotation: 0 – 360°
Day& Night	IR cut filter with auto switch
Wide Dynamic Range	120dB
Video Frame Rate	1080p@25fps/1080p@30fps
HD Video Output	1 Analog HD output
Synchronization	Internal Synchronization
S/N Ratio	More than 62 dB
Up the Coax	Support
Menu
Auto White Balance	Auto/MWB
BLC	Support
AGC	Support
Language	English/Chinese
Function	Wide Dynamic Range; Digital Noise reduction; Mirror; SMART IR
General
Operating Conditions	-40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing)
Power Supply	12 VDC±15%
Power Consumption	Max. 4.5W
IR Range	Up to 30m
Communication	Up the coax Protocol: HIKVISION-C(Coaxitron)
Dimension	φ136 × 102 mm (φ5.35” × 4.02”)
Weight	600 g
