Description

Camera
Image Sensor:		2MP CMOS Image Sensor
Signal System:		PAL/NTSC
Effective Pixels:		1928(H)*1088(V)
Min. Illumination:		0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter Time:		1/25(1/30) s to 1/50,000 s
Lens:		2.8mm, 3.6mm, 6mm, optional Angle of View: 103°(2.8mm), 82.2°(3.6mm), 54°(6mm)
Lens Mount:		M12
Adjustment Range:		Pan: 0 – 360°, Tilt: 0 – 90°, Rotation: 0 – 360°
Day& Night:		IR cut filter with auto switch
Wide Dynamic Range:		120dB
Video Frame Rate:		1080p@25fps/1080p@30fps
HD Video Output:		1 Analog HD output
Synchronization:		Internal Synchronization
S/N Ratio:		More than 62 dB
Up the Coax:		Support

Menu
Auto White Balance:		Auto/MWB
BLC:		Support
AGC:		Support
Language:		English/Chinese
Function:		Wide Dynamic Range; Digital Noise reduction; Mirror; SMART IR

General
Operating Conditions:		-40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing)
Power Supply:		12 VDC±15%
Power Consumption:		Max. 5W
Weather Proof:		IP66
IR Range:		Up to 20m
Communication :		Up the coax Protocol: HIKVISION-C(Coaxitron)
Dimension:		86.7mm×81.6mm×226mm (3.41″×3.23″×8.67″)
Weight:		Approx. 680g (1.5lb)
