Description
| Camera | ||
|---|---|---|
| Image Sensor: | 1MP CMOS Image Sensor | |
| Signal System: | PAL/NTSC | |
| Effective Pixels: | 1280(H)x960(V) | |
| Min. Illumination: | 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR | |
| Shutter Time: | 1/25(1/30) s to 1/50,000 s | |
| Lens: | 2.8 – 12 mm @ F1.4 | |
| Lens Mount: | φ14 | |
| Adjustment Range: | Pan: 0 – 360°, Tilt: 0 – 75°, Rotation: 0 – 360° | |
| Day& Night: | IR cut filter with auto switch | |
| Video Frame Rate: | 720p@25fps/720p@30fps | |
| HD Video Output: | 1 Analog HD output | |
| Synchronization: | Internal Synchronization | |
| S/N Ratio: | More than 62 dB | |
| General | ||
|---|---|---|
| Operation Condition: | -40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing) | |
| Power Supply: | 12 VDC±15% | |
| Power Consumption: | Max. 5 W | |
| Weather Proof: | IP66 | |
| IR Range: | Up to 40m | |
| Dimension: | Φ130.54 × 102.4mm (Φ5.1” × 4.0”) | |
| Weight: | 600g | |
