Description

System Parameters
Card Reading Frequency:		125KHz
1:N Face Recognition Duration:		≤ 1 s/Person
Operation System:		Linux
Fingerprint Module:		Optical, Red Backlight
Card Capacity:		5,000
Face Recognition Accuracy Rate:		≥ 99%
Card Type:		EM Card
Camera:		0.3 MP Wide-Angle
Fingerprint Capacity:		5,000
Event Capacity:		100,000
Face Recognition Distance:		0.3 m to 1 m
Face Capacity:		3,200

Device Interfaces
Communication Mode:		Ethernet 10/100Mbps Self-adaptive; Wi-Fi
Output Interface:		Doorbell × 1, Lock × 1, Alarm Output × 1
Input Interface:		RS-485 × 1, Wiegand × 1, Door Magnetic Sensor × 1, Exit Button × 1, Tamper × 1, Alarm Input × 2
USB Interface:		USB2.0

General
LCD Screen:		5-inch LCD Touch Screen; Resolution: 800 × 480
Lithium Battery:		Not Support
Power Supply:		12 VDC/2 A
Installation:		Base Mounting; Wall Mounting
Application Situation:		Indoor
Working Humidity:		10% to 90% (Non-Condensing)
Working Temperature :		-10°C to +50°C (14°F to +122°F)
Dimensions (L×W×H):		190mm × 157mm × 98mm (7.48” × 3.86” × 6.18″)
